7.8inch Electronic paper screen Black White Color 1404x1872 SPI
Customized
Accepted
Sample Stock
Small amount stock
MOQ
500pcs
Lead Time
4-6 weeks
Payment
Bank transfer/Alibaba/Paypal
Shipping Port
HK/SZ
Prodcuts Details
SDE0780NQE-11 7.8 inch Description:
Sunshine Display model SDE0780NQE-11 is a 7.8 inch e-paper display module with Black&White display colors, 1404*1872 resolution, and Parallel interface. Designed for ultra-low-power and bistable applications, it supports industrial ESL, smart signage, and IoT terminals with a work temperature range of 0-50°C.
Key Features & Advantages
- 7.8 inch e-paper module with Black&White display colors and 1404*1872 resolution for crisp, paper-like readability.
- Pixel density of 300 PPI helps balance detail and readability across different viewing distances.
- Bistable eink technology retains the image with near-zero power consumption after refresh, ideal for always-on labels and signage.
- Parallel interface for straightforward integration with industrial controllers and embedded systems.
- Work temperature range 0-50°C supports stable operation in commercial and industrial environments.
- Optional multi-image assets and specification sheets help accelerate mechanical evaluation and OEM/ODM customization.
Application
Typical applications include electronic shelf labels (ESL), smart retail tags, industrial instruments, logistics tags, conference badges, and low-power IoT / smart home information panels.
Specifications
Need the latest datasheet or drawing? Request documentation for SDE0780NQE-11.
| Feature | Specification | Unit |
|---|---|---|
| Brand | Sunshine Display | - |
| Model No. | SDE0780NQE-11 | - |
| Display Colors | Black&White | - |
| Inch | 7.8 | inch |
| Resolution | 1404*1872 | dots |
| AA Dimension | 118.6(H)x158.18(V) | mm |
| Outline Dimension | 127.6(H)x173.8(V)x0.87(D) | mm |
| PPI | 300 | - |
| Interface | Parallel | - |
| View Angle | 180 | - |
| Work Temperature | 0-50°C | ℃ |
Before design approval, confirm the specification revision, pin assignment, electrical limits and mechanical drawing. Agree on any project-specific inspection and aging conditions with our engineering team.
